Boom Sprayer for Sale - Tractors Implements
The Boom Sprayer is ideal for applying pesticides, fertilizers, and water to crops. It features a long boom, usually ranging from 15 to 60 feet wide, equipped with nozzles or spray tips that effectively distribute the liquid over the crops.
Technical Specifications:
| Specifications | |
| Tank Capacity | 450 lit, 500 lit, 650 lit, 750 lit |
| Tank Material | Fiber Glass with Agitation System |
| Spray Boom Length | 42.5 till 50 to 55 feet |
| Pump Type | Diaphragm type to be operated with PTO |
| Pump Speed | 500 RPM |
| Pump Out Put | 100 lit/min |
| Nozzle Type and Number | Hollow Cone Type |
| Number of Nozzles | 33 or 43 |
| Total Weight with Boom | 240 to 400 kg |
| Transportation width | 8.6 ft |
| Height of filling | 4.75 ft |
| Time of Tank Filling | 8 min. |
| Filters | Stainless steel filters in diff. parts of sprayer, tank inlet, pipes, each nozzle |
| Output | 8-10 Acre/Hr. |
| Tractor Compatibility | 60hp-85hp |
| Easy to operate Manual operation | |
| Adjustable boom height and width | |
| Multiple nozzles or spray tips | |
| Fiber Tank | |
| Tank capacity varies (e.g., 100-1,000 gallons) | |
| Optional features: Hydraulic Operations, GPS guidance, auto-section control, and flow control | |
